Autoclaved Aerated Concrete vertical structural panels

Load-Bearing Wall Systems That Perform Under Pressure

Autoclaved Aerated Concrete vertical structural panels are high-density, steel-reinforced elements used for structural walls and partitions. Engineered for durability and seismic performance, they’re ideal for multi-storey buildings, shear walls, and areas requiring long spans and high load capacity.

REQUEST A CUSTOM QUOTE

Dimensions (mm)	Density (kg/m³)	Compressive Strength (MPa)	Key Benefits
150x2440x600	600	4	Load-bearing for interior or perimeter walls
200x2440x600	600	4	Extra strength for multi-storey structures
250x2440x600	600	4	Extended height and load capacity
300x2440x600	600	4	Maximum vertical reinforcement
150x2745x600	600	4	Taller option for open-span wall systems
200x2745x600	600	4	Versatile for residential or commercial builds
250x2745x600	600	4	Structural use with added rigidity
300x2745x600	600	4	Ideal for demanding architectural designs
150x3050x600	600	4	Long-span walling for industrial builds
200x3050x600	600	4	For tall enclosures or service walls
250x3050x600	600	4	Reinforced vertical support for mid-rise
300x3050x600	600	4	Full structural strength in large formats

Key Benefits

Load-Bearing Capability: Reinforced to support structural loads in low- and mid-rise construction.
Efficient Wall Systems: High strength and energy dissipation for seismic safety zones.
Thermal & Acoustic Barrier: Adds insulation and noise reduction without added mass.
Seismic Performance: High strength and energy dissipation for seismic safety zones.

Applications

Lintels Over Openings: Commonly used above windows and doors to create strong, reinforced lintels with minimal prep.
Ring Beams: Used at floor levels or roof lines to tie wall structures together and resist lateral forces.
Horizontal Structural Support: U-Blocks can form beams that distribute loads over longer spans, especially in multi-storey buildings.

AAC Installation Training Program

In partnership with Portage College, Rocksolid offers practical AAC training for builders and crews. Learn efficient techniques and Canadian code compliance in on-site sessions.

Need more informations? Contact our team of experts.

Gavriil: +1 780-212-1148

Chris: +1 403-373-7497
